See Horizontal Bar Series

Aluminum Horizontal Bars

Clear

Current Selection:

Rise & Run Details

Please provide us with a valid stair angle to add this product to your cart.

Please Note - If your staircase contains a variable rise and run from step to step, you will need to work with a Project Manager after the sale to engineer the system.

Please check the box above to acknowledge the statement.

Ships in about 14 Business Days

Product Description

This newest horizontal infill offering has a substantial feel to it, while maintaining an open concept. Use your favorite modern box newels as supports,  drill at least 1″ deep holes for the bars to sit in, and fasten with epoxy. It doesn’t get much easier than that!

Key Features:

  • 5/8″ Aluminum Round Bars (Hollow)
  • 8′ Lengths
  • Made in America
  • Available in All Powder Coat Options
  • Easy Install
  • Interior or Exterior Use
  • Endurance Powder Coat is Coastally Rated
    • Coastal epoxy must be provided by customer

Instructions:

  • 42″ Tall Level Runs: With newels spaced under 8′, use 11 bars with 2 3/4″ spacing between bars (3 7/16″ on center)
  • 36″ Tall Angled Runs: With newels spaced under 8′, use 9 bars with 2 9/16″ spacing between bars (3 3/8″ on center)’
  • For End Posts: Use a 3/4″ Forstner Bit to drill your holes at the angle of the run at 1″ deep. Use epoxy to hold the bars in place.
